Junsi iCharger 406DUO

Description

Junsi iCharger 406DUO DC Battery Charger features:

• Advanced Technology: The 406DUO utilizes advanced Synchronous buck-boost DC/DC converter technology, providing high power, high current, and exceptional power conversion efficiency.
• Impressive Power Capacity: With a maximum charge power capacity of up to 1400W, this charger can handle demanding charging tasks efficiently.
• Dual Channels: Each channel supports 6s LiPo, Lilo, LiFe, and NiZn batteries. Additionally, it features a unique balance calculation with internal resistance correction.
• Flexible Battery Compatibility: The 406DUO supports a wide range of battery types, including 1-20s NiMH/NiCd batteries and 1-12s Pb batteries.
• Convenient USB Charging: Equipped with a 1A/5V USB charging port, it allows users to conveniently charge mobile phones and other devices.
• Anti-Spark Protection: When connecting the battery after powering on, the charger automatically activates anti-sparking protection.
• Intelligent Fan Control: The internal temperature sensor adjusts the fan speed to maintain optimal operating conditions.
• Temperature Protection: If the internal temperature exceeds safe limits, the charger reduces output power or shuts down to prevent damage.
• Parameter Storage: Save up to 64 parameter sets and easily import/export data via an SD card.
• Informative LCD Screen: The 2.8-inch LCD screen displays real-time information, including current, voltage, power, capacity, internal resistance, control status, time, and temperature.
• Multi-Discharge Modes: Choose from self-discharge, regenerative input discharge, and lithium battery extra expanding discharge.
• Internal Resistance Measurement: Measure the internal resistance of the entire battery pack and individual cells within lithium batteries.
• Comprehensive Protection: The iCharger safeguards against reversed polarity, input voltage/current issues, battery temperature, charging capacity, overrun time, and maximum power.
• Upgradeable Firmware: Easily upgrade the hardware program via USB port or SD card.
• Logview Software Support: Analyze charge and discharge data using the “Logview” software.



Specifications:
Net weight: 0.91kg
Dimension: 171×118×59 ±0.5mm
Input Voltage Range: 10.0—30.0VDC
Maximum Input Current Limit: <60A, CH1/2<47A
Maximum Charge/Discharge Current: 70A in sync mode, 40A in async mode
Maximum Charge Power Capacity: 1400W (Channel 1000W @input > 23.5V)
Maximum Discharge Power Capacity: 140W (Channel 80W)
Maximum Regenerative Discharge Power Capacity: 1400W (Channel 1000W)
Maximum Extra Discharge Power Capacity: 2000W (Channel 1000W @25V/40A)
Maximum Current Drain for Balancing: 2.4A in sync mode, 1.2A in async mode
USB Charging Port: 5V/1A?current-limiting protection 1.2A?

Includes:

• (2) Open ended 12awg charge leads
• (2) Balance board connector cables
• (1) 2 in 1 XH/EH type 2S/6S balance board
• (1) Open ended power supply cable
